TP-Link Omada EAP115-Wall 300mbps Wireless N Wall Plate
- Integrated into Omada SDN
- Centralized Management
- Elegant Appearance
- Easy Installation and PoE Support
- Secure Guest Network
- 6 Months Warranty
Perfectly Formed
The EAP115-Wall would blend seamlessly into any business setting with a refined, minimalist appearance. A slimline design includes casing that?s just 11 mm in thickness.
11 mm
Effortless Deployment
With 802.3af Power over Ethernet supported there?s no need for additional wiring. Simply plug in existing Ethernet cables and you?re ready to go.
Complete Wireless Coverage
An EAP in each room guarantees a strong wireless signal and allows guests to enjoy their own private Wi-Fi network.
Omada SDN?Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Hassle-Free Centralized Cloud Management:
100% centralized cloud management of whole network from different sites?all controlled from a single interface anywhere, anytime.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
RELATED SOLUTIONS
Hospitality
TP-Link Omada allows hotels to build reliable WiFi networks. Hotel WiFi network solutions including network topology, design, features, installation, and products are introduced.
Due to its reliable, scalable, and secure network solution, TP-Link has been widely acknowledged by global customers in the Education market ranging from infant schools with a few APs up to colleges and universities with hundreds of APs.
WiFi Marketing
Here you will have the opportunity to show them your products, services, offers, promotions or simply information related to your business. With TP-Link captive portal functions, boost your online business through guest Wi-Fi with Facebook Login, Voucher, and other flexible authentication options.
| HARDWARE FEATURES | |
|---|---|
| Interface | ? Uplink: 1_ 10/100 Mbps Ethernet Port ? Downlink: 1_ 10/100 Mbps Ethernet Port |
| Physical Security Lock | No |
| Button | ? LED/Wi-Fi Button ? RESET |
| Power Supply | PoE (IEEE 802.3af) |
| Power Consumption | 2.8 W |
| Dimensions ( W x D x H ) | 3.4 _ 3.4 _ 1.2 in (86.8 _ 86.8 _ 30.2 mm) |
| Antenna Type | Internal 2_ 1.8 dBi Omni |
| Mounting | Wall Plate Mounting |
| Hardware Watch Dog | Yes |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11n/g/b |
| Frequency | 2.4 GHz |
| Signal Rate | ? 11n: Up to 300 Mbps (dynamic) ? 11g: Up to 54 Mbps (dynamic) ? 11b: Up to 11 Mbps (dynamic) |
| Transmit Power | CE_ ?20 dBm (2.4 GHz) |
| Wireless Functions | ? Multiple SSIDs (Up to 8 SSIDs) ? Enable/Disable Wireless Radio ? Automatic Channel Assignment ? Transmit Power Control (Adjust Transmit Power on dBm) ? QoS(WMM) ? Load Balance ? Rate Limit ? Reboot Schedule ? Wireless Schedule ? Wireless Statistics based on SSID/AP/Client |
| Wireless Security | ? Captive Portal Authentication ? Access Control ? Wireless Mac Address Filtering ? Wireless Isolation Between Clients ? SSID to VLAN Mapping ? Local LAN port based VLAN ? Rogue AP Detection ? 802.1X Support ? 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
| MANAGEMENT | |
|---|---|
| Omada App | Yes |
| Centralized Management | ? Omada Hardware Controller (OC300) ? Omada Hardware Controller (OC200) ? Omada Software Controller |
| Cloud Access | Yes (Through OC300, OC200, or Omada Software Controller) |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1,v2c |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| OTHERS | |
|---|---|
| Certification | CE, RoHS |
| Package Contents | ? 300 Mbps Wireless N Wall-Plate Access Point EAP115-Wall ? Installation Guide ? Mounting Screw |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
| Environment | ? Operating Temperature: 0?40 _ (32?104 _) ? Storage Temperature: -40?70 _ (-40?158 _) ? Operating Humidity: 10?90% RH non-condensing ? Storage Humidity: 5?90% RH non-condensing |
